Continuous Output Accuracy ±0.10% URL (BFSL) Zero Balance & URL ±0.25% URL (Each) Turndown 5:1 Output 4-20mA HART 7 Communications ProtocolModbus RTU (RS-485) Serial Communications 1-5VDC (Low Power) Mode of Operation (36mW ± 5mW @ 10VDC) Temperature Effect ±1% URL/100oF @ -40 to -176oF Switch Output 1: Off 2: Windowed, Normally-Open 3: Windowed, Normally-Closed 4: Single Point, Normally-Open 5: Single Point, Normally-Closed 6: PWM (Pulse Width Modulation), Pulsed Low 7: PWM (Pulse Width Modulation), Pulsed High 8: Dead Band, Normally-Open 9: Dead Band, Normally-Closed Accuracy ±0.25% URL Type Normally Open Solid State Relay (SPST) Electrical Rating 30V, 120mA Temperature Effect ±1% URL/100oF @ -40 to 176oF Temperature Range Compensated -40 to 176oF (-40 to 80oC) Ambient -40 to 176oF (-40 to 80oC) Process -40 to 194oF (-40 to 90oC) Storage -40 to 194oF (-40 to 90oC) Long Term Stability < ±0.5% URL per year Response Time < 70 ms Supply Voltage 10-36VDC Loop Resistance 667 ohms @ 24VDC Circuit Protection Reverse polarity and EMC (EMI/RFI) protected Construction 316SS housing (CF8M) Process Connection 1/2” NPT(M) with 1/4” NPT(F) and Autoclave F250C (F) for 1/4” OD Tubing Electrical Connection Size 1/2” NPT(M) Termination 18 AWG shielded cable, 72-inch length Wetted Materials 316-SST (for pressure ranges 0-5 psi thru 0-100 psi) 17-4SST (for pressure ranges above 0-100 psi) Over Pressure 0-5 thru 0-100 psi 3 times FSPR 0-250 thru 0-10,000 psi 2 times FSPR Up to 30,000 psi 1.4 times FSPR Burst Pressure 0-5 thru 0-100 psi 4 times FSPR 0-250 psi 40 times FSPR 0-500 thru 0-1000 psi 20 times FSPR 0-2500 psi 10 times FSPR 0-5000 psi 8 times FSPR 0-10,000 thru 0-15,000 psi 4 times FSPR 0-30,000 psi 1.8 times FSPR Weight 1.8 lb (0.8 kg) Warranty
