ELECTRICAL CABLE SPAN MAGNETIC TARGET ZERO MAGNETIC TARGET 28.6 1-1/8 HEX Dimensions shown are for reference only. Contact the factory for certiffed dimension dApproved* Safety Method ApprovalFM (U.S. and Canada) Explosion Proof Hazardous Locations Class I, II, III; Division 1 Groups A-G; T5; Type 4X Non-incendive Class I, II, III; Division 2 Groups A-G; T5; Type 4X ATEX Flameproof II 2 G Ex d IIC T5 IP 66* Product holds a Canadian Registration Number (CRN) in all provinces, only available for Range options 04 thru 09.rawings. Linear = mm/in. Certiffcates* C1 C2 C3 C4 C8 D2Calibration ¿Hydrostatic Pressure Test ¿Inspection Report ¿Compliance / Conformance ¿Typical Material of Wetted Parts ¿Manufacturer’s Certiffcation*Only available for Range options 04 thru 08 **For pressure Ranges above 0-10,000 psi (Range options 10 and 11) ***Dual Seal version is not hermetically sealed. Only available for Range options 00 thru 09Note: The continuous zero and span points and the Switch Conffguration Mode and set point(s) must be speciffed. Refer to switch conffguration diagrams on page 3.Example: 815PT-Z07-A-RR, which has a range of 0-2500 psi could be ordered with zero and span of 200 psi and 2300 psi. The window mode switch conffguration could have a LO set point of 210 psi and a HI set point of 2290 psi.
