815PT Smart Pressure Transmitter815PT Smart Pressure Transmitter, HART 7 Communication Protocol with 4-20 mA Output, Modbus RTU (RS-485) Serial Communications, 1-5 VDC (Low-Power) Mode of Operation, Conffgurable Solid-State Switch Output, 0-2500 psi, 17-4SS Port, ½” NPT(M) with ¼” NPT(F) Process Connection, and Optional SS Tag Wired to Housing with Customer Speciffed Information.815PT - Z07 - A - RRStainless Steel, 1/2”NPT(M) with 1/4”NPT(F), Process Connection (316SS for ranges 0-100 psi and below) (17-4SS for ranges above 0-100 psi) 316SS, 1/2”NPT(M) Flush-Mount, Liquid-Filled, Diaphragm Seal, Process Connection* 17-4SS, Autoclave F250C Female (For 1/4” OD Tubing), Process Connection** 0-5 psi 0-15 psi 0-50 psi 0-100 psi 0-250 psi 0-500 psi 0-1000 psi 0-2500 psi 0-5000 psi 0-10000 psi 0-15000 psi 0-30000 psi Cleaned for industrial oxygen service Dual Seal approval (FM)*** Pipe mounting kit SS tag wired to housing with customer speciffed information *Only available for Range options 04 thru 08 **For pressure Ranges above 0-10,000 psi (Range options 10 and 11) ***Dual Seal version is not hermetically sealed. Only available for Range options 00 thru 09Note: The continuous zero and span points and the Switch Conffguration Mode and set point(s) must be speciffed. Refer to switch conffguration diagrams on page 3.Example: 815PT-Z07-A-RR, which has a range of 0-2500 psi could be ordered with zero and span of 200 psi and 2300 psi. The window mode switch conffguration could have a LO set point of 210 psi and a HI set point of 2290 psi.
